DATAVIDEO NVD-30 IP VIDEO DECODER

Request For Price

When connected to a Datavideo DVS-200 Cloud Streaming Server, the NVD-30 can function as an IPTV set-top box downloading a channel list of both live and pre-recorded streams automatically.

Category: DataVideo

SKU: 10

Decodes video from Datavideo encoders, Youtube and Vimeo

The NVD-30 decodes all common protocols which allow it to decode directly from YouTube Live, UStream, and most major CDNs without any 3rd party advertising.

STB functionality for use as a set-top-box

When connected to a Datavideo DVS-200 Cloud Streaming Server, the NVD-30 can function as an IPTV set-top box downloading a channel list of both live and pre-recorded streams automatically.

Available in HDMI

The Datavideo NVD-30 is a wired IP video decoder with HDMI, Composite video outputs at resolutions up to 1080p30.

Item Included:

Datavideo IP Video Decoder with HDMI Output

12 VDC AD Switch

Remote Control

Product Highlights:

HDMI and Composite BNC Outputs
Up to 1080p60 Resolution Output
Stereo RCA and Embedded Audio Output
Supports RTMP and Other Common Protocols

NVD-30 - Specification

More Information

General Specifications
Audio/Video Input:	Stream Input · RTSP over UDP (Unicast / Multicast) · RTSP over TCP · RTSP over HTTP · MPEG-TS over UDP · RTMP over TCP · UDP raw (Unicast/Multicast) · HLS over HTTP · MPEG-TS over TCP Pull · Video-sharing websites
Audio Output:	2 x RCA(L/R) HDMI embedded audio
:
Video Output:	Composite (analog) HDMI (digital)
:
Network Feature:	1x RJ-45 Female (10/100M Ethernet) DHCP/Static IP
Supported Video Resolution:	1080p 60/59.94/30/29.97/25/24 1080i 60/59.94/50 720p 60/59.94/50 576i 50 (PAL) 480i 60 (NTSC)
Control:	Web browser UI for configuration and control. TCP/IP Socket commands
Update:	Automatic firmware upgrade
Power:	DC 12V, 0.5A
Environmental Conditions:	Operating temperature: 0~40°C, Storage temperature: -10~60°C
Dimension (LxWxH):	220 x 143 x 47 mm
Weight:	1 kg
What's in the Box:	1 x NVD-30 product 1 x AD Switch DC 12V 1 x Thank You Card 1 x Remote Control
