- 1" (effective) CMOS sensor with high picture quality
- F12 Sensitivity
- Sports and Broadcast overlay on video and streaming
- NDI|HX output capability in Full HD up to 20Mbps
- 4K UHD 60p/50p ProRes 4:2:2 10-bit recording to SSD*
- NEW HD Recording to SSD*
- 4K UHD 30p/25p/24p 4:2:0 8-bit recording to SDHC/SDXC card
- HDR recording, HLG, or J-Log1 (10-bit)
- Backup to SSD*
- Newly-developed 4K lens with 20x zoom
- 40x lossless dynamic zoom
- 4K Rec + HD streaming + 4K HDMI output
- Low latency and high-quality streaming up to 20Mbps
- NEW SRT Live Streaming Protocol (optional selection ZIXI or SRT) also RTMPS Protocol available
- NTP Time server supported
- High performance 1080 60p/50p live streaming
- Auto FTP to upload native video clips automatically
- NEW Progressive Auto FTP File transfer
- Return over IP (Return video and IFB)
- Built-in wireless LAN (2.4GHz/5GHz) MIMO with external antenna
- LAN terminal (Streaming/IFB/Remote) in addition to USB host (v3.0)
- 4-inch high-resolution LCD monitor
- XLR audio connectors
Items Included:
Battery
Yes, BN-VC296G
AC/DC adapter
Yes, AC Adapter
Cable 1
Yes, the Power cord
Additionals
Yes, Wireless Antennas 2x, Lens Cap
More Information
SPECS
Camera Front-End Specifications:
- Image Sensor (inch): 1" (effective) CMOS
- Number of Sensors: 1
- Mega Pixels: 9.35 mio
- Sensitivity in F at 2000 Lux: F 12
- Shutter speed: 1/6 to 1/10000
- White Balance Modes: FAW, AWA, 3200K, 5600K, Manual
- Color Matrix adjustment: Yes
- Wide Dynamic Range Mode (WDR): Yes
- HDR (High Dynamic Range): Yes, HLG/JLOG 1
- LOG Mode: Yes, J-LOG HLR
- User-selected function buttons: Yes
- User Customizes Menu: Yes
Optical Specifications:
- Lens Mount: Internal
- Optical Zoom X times: 20
- Dynamic Zoom x times: 40
- Lens F Number: 2.8 to 4.5
- Lens ratio from/to: 9.43mm to 188.6mm
- Lens ratio equivalent to 35mm: 28mm to 560mm
- Auto Focus: Yes
- Optical Image stabilization: Yes
- Filter Diameter in mm: 82mm
- Built-in ND Filters: 3 Filters - 1/4, 1/16, 1/64 plus OPEN
Recording Formats:
- Media: SDHC/SDXC memory card x 2 plus M2 SSD Slot with Adapter* optional
- Media Class: 4K/70 Mbps, HD and below Class 10 4K/150Mbps UHS1-U3 (no UHS-2)
- Recording slots: 3
- Encoder: ProRes, MPEG-4 AVC/H.264 (HD/SD), MPEG-2 (HD)
- ProRes Recording: Yes
- File Format MOV: Yes
- File Format MP4: Yes
- File Format MXF: Yes
- Video Codec MPEG2 Long GOP: Yes
- Video Codec MPEG4 AVC/H264 4K/HD: Yes
- Video Codec H264 (SD): Yes
- Video Codec others: 4K UHD ProRes / Proxy H264
